211Basic Procedure for Wipe Settings
Chapter 5 Wipes
Soft: You can adjust the edge softness.
Soft border: You can adjust the border width, and the softness of the inner and
outer edges of the border.
When a border or soft border is selected, the signal filling the border is called
edge fill. For the edge fill, you can use a matte generated by the dedicated color
matte generator, or the signal selected on the utility 2 bus. A matte can include
color 1 and color 2, and a combination of the two colors (a “color mix”).
1
In the M/E-1 >Wipe menu, select HF4 ‘Edge/Direction.’
The Edge/Direction menu appears.
2
In the <Edge> group, select the edge type.
Border: border
Soft: soft edge
Soft Border: soft border
3
Set the parameters according to the selection in step 2.
• When border is selected
• When soft edge is selected
• When soft border is selected
4
When you selected border or soft border, select the edge fill signal in the
<Edge Fill> group.
Utility 2 Bus: signal selected on the utility 2 bus
Matte: signal from the dedicated color matte generator
5
Depending on the operation in step 4, carry out the following operation.
When ‘Utility 2 Bus’ is selected: Press the key delegation button
[UTIL2], turning it on, and select the signal in the key row.
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
2 Inner Soft Border inner softness 0.00 to 100.00
3 Outer Soft Border outer softness 0.00 to 100.00
