221Basic Procedure for Wipe Settings
Chapter 5 Wipes
• The parameter H Offset determines the spacing in the horizontal direction.
If a negative value is set, the even-numbered pairs of strip and slit move to
the left, and the odd-numbered pairs move to the right. (The value –100.00
represents the maximum movement.)
If a positive value is set, the even-numbered pairs of strip and slit move to
the right, and the odd-numbered pairs move to the left. (The value +100.00
represents the maximum movement.)
• The parameter V Offset determines the spacing in the vertical direction.
If a negative value is set, the even-numbered pairs of strip and slit move
upward, and the odd-numbered pairs move downward. (The value –100.00
represents the maximum movement.)
If a positive value is set, the even-numbered pairs of strip and slit move
downward, and the odd-numbered pairs move upward. (The value +100.00
represents the maximum movement.)
1
In the M/E-1 >Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2
In the <Pairing> group, select the slit direction.
H: Create slits in the horizontal direction.
V: Create slits in the vertical direction.
3
Set the following parameters.
Applying modulation to the wipe pattern (Modulation)
The pattern signal can be modulated, giving waves on the horizontal or vertical
edges, or radially.
The parameter Shape determines the form of the modulation.
1: sine wave, 2: triangular wave, 3: rectangular wave
Knob Parameter Adjustment Setting values
1 Width Width of the slits 1 to 128 (integer)
2 H Offset Spacing in the horizontal direction
–100.00 to +100.00
3 V Offset Spacing in the vertical direction
–100.00 to +100.00
