359Simple P/P Software
Chapter 10 Special Functions
• A processed key cannot be used. Therefore, it is not possible to apply a DME
effect to a downstream key.
• As an independent key transition type, wipe and DME wipe cannot be used.
Restrictions on executing transitions in the transition control
block
• DME wipes cannot be used.
• Wipes can be used, but there are restrictions on use. For details, see the next
item, “Restrictions when using wipes.”
Restrictions when using DME wipes
• The wipe patterns that can be used are standard wipes (pattern numbers 1 to
24) only.
• A pattern mix cannot be used.
• A split (splitting the wipe pattern) cannot be used.
• When a border or soft border is selected for a wipe edge, the signal to be
inserted in the edge (edge fill) is restricted as follows.
– The utility 2 bus cannot be selected.
– When using a matte, a mix color cannot be used.
– Even if the wipe border width is set to the same numeric value for M/E and
Simple P/P, the same image is not obtained.
• The following wipe modifiers cannot be used:
– Replication “Shift” and Multi Adjust menu adjustments
–Pairing
– Modulation
–Spring
–Spiral
• Changing modifier parameter settings changes the wipe pattern size.
Restrictions on utility buses
The utility 1 and utility 2 buses cannot be used.
Assignment of signals to output connectors
Connectors to which the P/P row output signal assignment is fixed
The assignment of the following signals to output connectors OUT17 to OUT2
2 is fixed.
Output
connector
Fixed assigned outputs
Standard mode Multi-program mode
DSK mode
a)
OUT17 Program
P/P OUT1
b)
Program 1
OUT18 Program
P/P OUT1
b)
Program 2
