Sony DVS-9000 System - Page 458

Chapter 11 DME Operations
458
DME Special Effect Operations
Adjusting the position of art edges
1 In the Art Edge menu, press [Edge Position], turning it on.
2 Adjust the following parameters.
The valid ranges of the parameter values depend on the aspect ratio (4:3/
16:9) selected in the system, as follows.
•4:3 mode
• 16:9 mode
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Width of top edge 0.00 to 4.50
2 Left Width of left edge 0.00 to 8.00
3 Right Width of right edge 0.00 to 8.00
4 Bottom Width of bottom edge 0.00 to 4.50
5 Density Density of edges 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Top Position of top edge –3.00 to +3.00
2 Left Position of left edge –4.00 to +4.00
3 Right Position of right edge –4.00 to +4.00
4 Bottom Position of bottom edge –3.00 to +3.00
5 All Adjust the position of all four
edges
Value of H shown
Knob Parameter Adjustment Setting values
1 Top Position of top edge –2.25 to +2.25
2 Left Position of left edge –4.00 to +4.00
3 Right Position of right edge –4.00 to +4.00
4 Bottom Position of bottom edge –2.25 to +2.25
5 All Adjust the position of all four
edges
Value of H shown
