509DME Special Effect Operations
Chapter 11 DME Operations
Blind settings
There are two modes: Bar and Wedge. You can set the number of rotations by
blocks, the perspective, the width and position of blocks, the direction, the
center position, and other parameters.
To apply the Blind effect
With the Blind menu displayed, use the following procedure.
1
In the <Mode> group, select [Bar] or [Wedge].
2
To make transition settings, press [Transition] and set the following
parameters.
3
To set the partition method, press [Partition] and set the following
parameters.
• When Bar was selected in step 1
• When Wedge was selected in step 1
To set the wedge center position
When Wedge is selected in the <Mode> group, you can set the wedge center
position.
1
Press [Position].
2
Set the following parameters.
Knob Parameter Adjustment Setting values
1 Rotation Number of rotations of the blocks –8.000 to +8.000
2 Perspective Degree of randomness in distance
moved by each block
0.000 to 100.000
Knob Parameter Adjustment Setting values
1 Width Width of partition 0.000 to 100.000
2 Offset Degree of randomness in partition
width
–5.000 to +5.000
3 Angle Starting angle of effect –8.000 to +8.000
Knob Parameter Adjustment Setting values
4 No Width of blocks 0.000 to 100.000
5 Phase Partition position –8.000 to +8.000
Knob Parameter Adjustment Setting values
1 H Horizontal center position –8.000 to +8.000
