515DME Special Effect Operations
Chapter 11 DME Operations
To make only the lens part visible
Press [Lens Only], turning it on.
The parts of the image outside the lens are removed.
To set the lens center position
1 Press [Position], turning it on.
2 Set the following parameters.
Circle settings
You can set the size of the circle, and make the axis of modulation vertical.
To apply the Circle effect
With the Circle menu displayed, set the following parameters.
To make the axis of modulation vertical
Press [Mod V], turning it on.
The axis of modulation when converting to the circle becomes vertical.
Panorama settings
You can set the horizontal and vertical curve ratio, and the curve center
position.
To apply the Panorama effect
With the Panorama menu displayed, set the following parameters.
2 Curve V Vertical curve ratio –100.00 to +100.00
3 Size V Vertical size 0.00 to 100.00
Parameter group [2/2]
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 H Horizontal lens center position –5.000 to +5.000
2 V Vertical lens center position –4.000 to +4.000
Knob Parameter Adjustment Setting values
1 Radius Size of circle 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Curve H Horizontal curve ratio –100.00 to +100.00
2 Curve V Vertical curve ratio –100.00 to +100.00
