Chapter 11 DME Operations
514
DME Special Effect Operations
You can also choose to display only the portion of the image that is seen
through the lens.
To apply the Lens effect
With the Lens menu displayed, use the following procedure.
1 In the <Mode> group, select the lens shape.
•Circle
• Rectangle
•Star
• Heart
•Bar
•Cross
2 Depending on the selected lens shape, set the following parameters.
• When Circle, Rectangle, Star, or Heart is selected
• When Bar is selected
• When Cross is selected
Knob Parameter Adjustment Setting values
1 Magnify H Magnification ratio –100.00 to +100.00
2 Curve H Curve ratio –100.00 to +100.00
3 Size H Size 0.00 to 100.00
4 Angle Slant angle –8.000 to +8.000
5 Aspect Aspect ratio –100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Magnify H Magnification ratio –100.00 to +100.00
2 Curve H Curve ratio –100.00 to +100.00
3 Size H Size 0.00 to 100.00
4 Angle Slant angle –8.000 to +8.000
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Magnify H Horizontal magnification ratio –100.00 to +100.00
2 Curve H Horizontal curve ratio –100.00 to +100.00
3 Size H Horizontal size 0.00 to 100.00
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Magnify V Vertical magnification ratio –100.00 to +100.00
