513DME Special Effect Operations
Chapter 11 DME Operations
2
Set the following parameters.
Kaleidoscope settings
You can set the number of blocks, the partition reference point and angle,
horizontal and vertical offsets, a reflection position, and other parameters.
To apply the Kaleidoscope effect
With the Kaleidoscope menu displayed, set the following parameters.
To reflect the kaleidoscope image as if in a mirror
1
To reflect in the horizontal direction, press [Mirror H], turning it on.
2
To reflect in the vertical direction, press [Mirror V], turning it on.
To set the reflection position
1
Press [Position], turning it on.
2
Set the following parameters.
To cyclically repeat part of the original and its reflection
Press [Cyclic], turning it on.
Lens settings
You can set the shape and aspect ratio of the lens, the angle, the magnification
ratio, the curve ratio, the size, the center position, and other parameters.
Knob Parameter Adjustment Setting values
1 H Horizontal original image center
position
–4.000 to +4.000
2 V Vertical original image center
position
–4.000 to +4.000
Knob Parameter Adjustment Setting values
1 Number Number of blocks 0.00 to 100.00
2 Phase Angle of partition reference point –8.000 to +8.000
3 Offset H Amount of horizontal offset –4.000 to +4.000
4 Offset V Amount of vertical offset –3.000 to +3.000
Knob Parameter Adjustment Setting values
1 H Horizontal reflection position
0.000 to 4.000
2 V Vertical reflection position
0.000 to 3.000
