Chapter 11 DME Operations
564
Global Effect Operations
If the Mix1 setting is 70 and the Mix2 setting is 40, the proportions of the
channels in the mixed portions in the previous illustration are as shown in the
following table.
Pairwise mixing of Ch1 and Ch2, and Ch3 and Ch4
If the Mix1 setting is 70 and the Mix2 setting is 40, the proportions of the
channels in the mixed portions in the previous illustration are as shown in the
following table.
Ch1 crossed with Ch2
Combination Indication in figure Ch1 Ch2 Ch3
Ch1 and Ch2 30% 70% –
Ch2 and Ch3 – 60% 40%
Ch1 and Ch3 30% – 70%
Ch1, Ch2, and Ch3 30% 42% 28%
Combination Indication in figure Ch1 Ch2 Ch3 Ch4
Ch1 and Ch2 30% 70% – –
Ch3 and Ch4 – – 60% 40%
Ch1
Ch2
1
2
Mix1
Ch1
Ch2
Ch3
Ch4
3
4
Mix2
Ch3
Ch4
Ch1
Ch2
1
2
Depth
