573Global Effect Operations
Chapter 11 DME Operations
Note
When the Combiner function is off, the shadow effect cannot be used.
Applying the Drop Shadow effect
The Shadow menu allows you to apply the Drop Shadow effect. To access the
Shadow menu, in the Global Effect>Ch1 - Ch4 menu select HF3 ‘Shadow.’
Depending on the selected combiner channels, the valid buttons differ as
follows.
Taking Ch1 Shadow as an example, the following explains the procedure for
applying the Drop Shadow effect.
1
Press [Ch1 Shadow], turning it on.
The Drop Shadow effect is enabled, and channel 2 becomes the channel for
the shadow to the image. You can adjust the position and density of the
shadow with the knobs.
Note
The flex shadow function cannot be enabled when Drop Shadow is
enabled.
However, the flex shadow function is not supported on the MVE-8000A.
2
Set the parameters.
3
In the <Ch1 Shadow Source> group, select the shadow source signal.
Video: Select Ch2 video input as the shadow.
Flat Color: Select a matte color as the shadow.
Combiner channel
selection
Button
Ch1
Shadow
Ch2
Shadow
Ch3
Shadow
Ch1+Ch2
Shadow
Ch2+Ch3
Shadow
Ch1+Ch2 Valid
Ch2+Ch3 Valid
Ch3+Ch4 Valid
Ch1+Ch2+Ch3 Valid Valid Valid
Ch2+Ch3+Ch4 Valid Valid Valid
Ch1+Ch2+Ch3+Ch4 Valid Valid Valid Valid
Knob Parameter Adjustment Setting values
1 Position H Horizontal shadow position
–8.00 to +8.00
2 Position V Vertical shadow position –8.00 to +8.00
3 Density Density of shadow 0.00 to 100.00
