ST STM32F2 User Manual

LL TIM Generic Driver
UM1940
1238/1371
DocID028236 Rev 2
LL_TIM_TRGO_CC1IF
CC1 capture or a compare match is used as trigger output
LL_TIM_TRGO_OC1REF
OC1REF signal is used as trigger output
LL_TIM_TRGO_OC2REF
OC2REF signal is used as trigger output
LL_TIM_TRGO_OC3REF
OC3REF signal is used as trigger output
LL_TIM_TRGO_OC4REF
OC4REF signal is used as trigger output
Trigger Selection
LL_TIM_TS_ITR0
Internal Trigger 0 (ITR0) is used as trigger input
LL_TIM_TS_ITR1
Internal Trigger 1 (ITR1) is used as trigger input
LL_TIM_TS_ITR2
Internal Trigger 2 (ITR2) is used as trigger input
LL_TIM_TS_ITR3
Internal Trigger 3 (ITR3) is used as trigger input
LL_TIM_TS_TI1F_ED
TI1 Edge Detector (TI1F_ED) is used as trigger input
LL_TIM_TS_TI1FP1
Filtered Timer Input 1 (TI1FP1) is used as trigger input
LL_TIM_TS_TI2FP2
Filtered Timer Input 2 (TI12P2) is used as trigger input
LL_TIM_TS_ETRF
Filtered external Trigger (ETRF) is used as trigger input
Update Source
LL_TIM_UPDATESOURCE_REGULAR
Counter overflow/underflow, Setting the UG bit
or Update generation through the slave mode
controller generates an update request
LL_TIM_UPDATESOURCE_COUNTER
Only counter overflow/underflow generates an
update request
Exported_Macros
__LL_TIM_CALC_DEADTIME
Description:
HELPER macro calculating DTG[0:7] in the
TIMx_BDTR register to achieve the requested dead
time duration.
Parameters:
__TIMCLK__: timer input clock frequency (in Hz)
__CKD__: This parameter can be one of the
following values:
LL_TIM_CLOCKDIVISION_DIV1
LL_TIM_CLOCKDIVISION_DIV2
LL_TIM_CLOCKDIVISION_DIV4
__DT__: deadtime duration (in ns)
Return value:
DTG[0:7]
Notes:
ex: __LL_TIM_CALC_DEADTIME (80000000,
LL_TIM_GetClockDivision (), 120);
__LL_TIM_CALC_PSC
Description:
HELPER macro calculating the prescaler value to
