UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1331
/1371
Register
Field
Function
LL_I2C_ReceiveData8
LL_I2C_TransmitData8
OAR1
ADD0
LL_I2C_SetOwnAddress1
ADD1_7
LL_I2C_SetOwnAddress1
ADD8_9
LL_I2C_SetOwnAddress1
ADDMODE
LL_I2C_SetOwnAddress1
OAR2
ADD2
LL_I2C_SetOwnAddress2
ENDUAL
LL_I2C_DisableOwnAddress2
LL_I2C_EnableOwnAddress2
LL_I2C_IsEnabledOwnAddress2
SR1
ADD10
LL_I2C_IsActiveFlag_ADD10
ADDR
LL_I2C_ClearFlag_ADDR
LL_I2C_IsActiveFlag_ADDR
AF
LL_I2C_ClearFlag_AF
LL_I2C_IsActiveFlag_AF
ARLO
LL_I2C_ClearFlag_ARLO
LL_I2C_IsActiveFlag_ARLO
BERR
LL_I2C_ClearFlag_BERR
LL_I2C_IsActiveFlag_BERR
BTF
LL_I2C_IsActiveFlag_BTF
OVR
LL_I2C_ClearFlag_OVR
LL_I2C_IsActiveFlag_OVR
PECERR
LL_I2C_ClearSMBusFlag_PECERR
LL_I2C_IsActiveSMBusFlag_PECERR
RXNE
LL_I2C_IsActiveFlag_RXNE
SB
LL_I2C_IsActiveFlag_SB
SMBALERT
LL_I2C_ClearSMBusFlag_ALERT
LL_I2C_IsActiveSMBusFlag_ALERT
STOPF
LL_I2C_ClearFlag_STOP
LL_I2C_IsActiveFlag_STOP
TIMEOUT
LL_I2C_ClearSMBusFlag_TIMEOUT
LL_I2C_IsActiveSMBusFlag_TIM
EOUT
TXE
LL_I2C_IsActiveFlag_TXE
SR2
BUSY
LL_I2C_IsActiveFlag_BUSY
DUALF
LL_I2C_IsActiveFlag_DUAL
GENCALL
LL_I2C_IsActiveFlag_GENCALL
1330
1332
