UM1940
1344
/1371
DocID028236 Re
v 2
Register
Field
Function
TSF
LL_RTC_ClearFlag_TS
LL_RTC_IsActiveFlag_TS
TSOVF
LL_RTC_ClearFlag_TSOV
LL_RTC_IsActiveFlag_TSOV
W
UTF
LL_RTC_ClearFlag_WUT
LL_RTC_IsActiveFlag_WUT
W
UT
W
F
LL_RTC_IsActiveFlag_WUTW
PRER
PREDIV_A
LL_RTC_GetAsynchPrescaler
LL_RTC_SetAsynchPrescaler
PREDIV_S
LL_RTC_GetSynchPrescaler
LL_RTC_SetSynchPrescaler
TAFCR
ALARMOUTTYPE
LL_RTC_GetAlarmOutputType
LL_RTC_SetAlarmOutputType
TAMP1E
LL_RTC_TAMPER_Disable
LL_RTC_TAMPER_Enable
TAMP1INSEL
LL_RTC_TAMPER_GetPin
LL_RTC_TAMPER_SetPin
TAMP1TRG
LL_RTC_TAMPER_DisableActiveLevel
LL_RTC_TAMPER_EnableActiveLevel
TAMPIE
LL_RTC_DisableIT_TAMP
LL_RTC_EnableIT_TAMP
LL_RTC_IsEnabledIT_TAMP
TSINSEL
LL_RTC_TS_GetPin
LL_RTC_TS_SetPin
TR
HT
LL_RTC_TIME_Config
LL_RTC_TIME_Get
LL_RTC_TIME_GetHour
LL_RTC_TIME_SetHour
HU
LL_RTC_TIME_Config
LL_RTC_TIME_Get
LL_RTC_TIME_GetHour
LL_RTC_TIME_SetHour
MNT
LL_RTC_TIME_Config
LL_RTC_TIME_Get
LL_RTC_TIME_GetMinute
LL_RTC_TIME_SetMinute
1343
1345
