UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1345
/1371
Register
Field
Function
MNU
LL_RTC_TIME_Config
LL_RTC_TIME_Get
LL_RTC_TIME_GetMinute
LL_RTC_TIME_SetMinute
PM
LL_RTC_TIME_Config
LL_RTC_TIME_GetFormat
LL_RTC_TIME_SetFormat
ST
LL_RTC_TIME_Config
LL_RTC_TIME_Get
LL_RTC_TIME_GetSecond
LL_RTC_TIME_SetSecond
SU
LL_RTC_TIME_Config
LL_RTC_TIME_Get
LL_RTC_TIME_GetSecond
LL_RTC_TIME_SetSecond
TSDR
DT
LL_RTC_TS_GetDate
LL_RTC_TS_GetDay
DU
LL_RTC_TS_GetDate
LL_RTC_TS_GetDay
MT
LL_RTC_TS_GetDate
LL_RTC_TS_GetMonth
MU
LL_RTC_TS_GetDate
LL_RTC_TS_GetMonth
W
DU
LL_RTC_TS_GetDate
LL_RTC_TS_GetWeekDay
TSTR
HT
LL_RTC_TS_GetHour
LL_RTC_TS_GetTime
HU
LL_RTC_TS_GetHour
LL_RTC_TS_GetTime
MNT
LL_RTC_TS_GetMinute
LL_RTC_TS_GetTime
MNU
LL_RTC_TS_GetMinute
LL_RTC_TS_GetTime
PM
LL_RTC_TS_GetTimeFormat
ST
LL_RTC_TS_GetSecond
LL_RTC_TS_GetTime
