Correspondence
between API registers
and API
low-layer driver functi
ons
UM1940
1354
/1371
DocID028236 Re
v 2
Register
Field
Function
OC1PE
LL_TIM_OC_DisablePreload
LL_TIM_OC_EnablePreload
LL_TIM_OC_IsEnabledPreload
OC2CE
LL_TIM_OC_DisableClear
LL_TIM_OC_EnableClear
LL_TIM_OC_IsEnabledClear
OC2FE
LL_TIM_OC_DisableFast
LL_TIM_OC_EnableFast
LL_TIM_OC_IsEnabledFast
OC2M
LL_TIM_OC_GetMode
LL_TIM_OC_SetMode
OC2PE
LL_TIM_OC_DisablePreload
LL_TIM_OC_EnablePreload
LL_TIM_OC_IsEnabledPreload
CCMR2
CC3S
LL_TIM_IC_Config
LL_TIM_IC_GetActiveInput
LL_TIM_IC_SetActiveInput
LL_TIM_OC_ConfigOutput
CC4S
LL_TIM_IC_Config
LL_TIM_IC_GetActiveInput
LL_TIM_IC_SetActiveInput
LL_TIM_OC_ConfigOutput
IC3F
LL_TIM_IC_Config
LL_TIM_IC_GetFilter
LL_TIM_IC_SetFilter
IC3PSC
LL_TIM_IC_Config
LL_TIM_IC_GetPrescaler
LL_TIM_IC_SetPrescaler
IC4F
LL_TIM_IC_Config
LL_TIM_IC_GetFilter
LL_TIM_IC_SetFilter
IC4PSC
LL_TIM_IC_Config
LL_TIM_IC_GetPrescaler
LL_TIM_IC_SetPrescaler
OC3CE
LL_TIM_OC_DisableClear
LL_TIM_OC_EnableClear
1353
