UM1940
Correspondence
between API reg
isters and API
low-layer driver functi
ons
DocID028236 Re
v 2
1355
/1371
Register
Field
Function
LL_TIM_OC_IsEnabledClear
OC3FE
LL_TIM_OC_DisableFast
LL_TIM_OC_EnableFast
LL_TIM_OC_IsEnabledFast
OC3M
LL_TIM_OC_GetMode
LL_TIM_OC_SetMode
OC3PE
LL_TIM_OC_DisablePreload
LL_TIM_OC_EnablePreload
LL_TIM_OC_IsEnabledPreload
OC4CE
LL_TIM_OC_DisableClear
LL_TIM_OC_EnableClear
LL_TIM_OC_IsEnabledClear
OC4FE
LL_TIM_OC_DisableFast
LL_TIM_OC_EnableFast
LL_TIM_OC_IsEnabledFast
OC4M
LL_TIM_OC_GetMode
LL_TIM_OC_SetMode
OC4PE
LL_TIM_OC_DisablePreload
LL_TIM_OC_EnablePreload
LL_TIM_OC_IsEnabledPreload
CCR1
CCR1
LL_TIM_IC_GetCaptureCH1
LL_TIM_OC_GetCompareCH1
LL_TIM_OC_SetCompareCH1
CCR2
CCR2
LL_TIM_IC_GetCaptureCH2
LL_TIM_OC_GetCompareCH2
LL_TIM_OC_SetCompareCH2
CCR3
CCR3
LL_TIM_IC_GetCaptureCH3
LL_TIM_OC_GetCompareCH3
LL_TIM_OC_SetCompareCH3
CCR4
CCR4
LL_TIM_IC_GetCaptureCH4
LL_TIM_OC_GetCompareCH4
LL_TIM_OC_SetCompareCH4
CNT
CNT
LL_TIM_GetCounter
LL_TIM_SetCounter
CR1
ARPE
LL_TIM_DisableARRPreload
LL_TIM_EnableARRPreload
1354
1356
