ST STM32F2 User Manual

LL ADC Generic Driver
UM1940
730/1371
DocID028236 Rev 2
LL_ADC_AWD_CHANNEL_6_INJ
LL_ADC_AWD_CHANNEL_6_REG_INJ
LL_ADC_AWD_CHANNEL_7_REG
LL_ADC_AWD_CHANNEL_7_INJ
LL_ADC_AWD_CHANNEL_7_REG_INJ
LL_ADC_AWD_CHANNEL_8_REG
LL_ADC_AWD_CHANNEL_8_INJ
LL_ADC_AWD_CHANNEL_8_REG_INJ
LL_ADC_AWD_CHANNEL_9_REG
LL_ADC_AWD_CHANNEL_9_INJ
LL_ADC_AWD_CHANNEL_9_REG_INJ
LL_ADC_AWD_CHANNEL_10_REG
LL_ADC_AWD_CHANNEL_10_INJ
LL_ADC_AWD_CHANNEL_10_REG_INJ
LL_ADC_AWD_CHANNEL_11_REG
LL_ADC_AWD_CHANNEL_11_INJ
LL_ADC_AWD_CHANNEL_11_REG_INJ
LL_ADC_AWD_CHANNEL_12_REG
LL_ADC_AWD_CHANNEL_12_INJ
LL_ADC_AWD_CHANNEL_12_REG_INJ
LL_ADC_AWD_CHANNEL_13_REG
LL_ADC_AWD_CHANNEL_13_INJ
LL_ADC_AWD_CHANNEL_13_REG_INJ
LL_ADC_AWD_CHANNEL_14_REG
LL_ADC_AWD_CHANNEL_14_INJ
LL_ADC_AWD_CHANNEL_14_REG_INJ
LL_ADC_AWD_CHANNEL_15_REG
LL_ADC_AWD_CHANNEL_15_INJ
LL_ADC_AWD_CHANNEL_15_REG_INJ
LL_ADC_AWD_CHANNEL_16_REG
LL_ADC_AWD_CHANNEL_16_INJ
LL_ADC_AWD_CHANNEL_16_REG_INJ
LL_ADC_AWD_CHANNEL_17_REG
LL_ADC_AWD_CHANNEL_17_INJ
LL_ADC_AWD_CHANNEL_17_REG_INJ
LL_ADC_AWD_CHANNEL_18_REG
LL_ADC_AWD_CHANNEL_18_INJ
LL_ADC_AWD_CHANNEL_18_REG_INJ
Notes
Usage of the returned channel number: To reinject this
channel into another function LL_ADC_xxx: the returned
channel number is only partly formatted on definition of literals
LL_ADC_CHANNEL_x. Therefore, it has to be compared with
parts of literals LL_ADC_CHANNEL_x or using helper macro
__LL_ADC_CHANNEL_TO_DECIMAL_NB(). Then the
selected literal LL_ADC_CHANNEL_x can be used as
parameter for another function.To get the channel number in
decimal format: process the returned value with the helper
macro __LL_ADC_CHANNEL_TO_DECIMAL_NB().
Applicable only when the analog watchdog is set to monitor
one channel.
On this STM32 serie, there is only 1 kind of analog watchdog
instance: AWD standard (instance AWD1): channels
monitored: can monitor 1 channel or all channels.groups
