LL ADC Generic Driver
UM1940
776/1371
DocID028236 Rev 2
setting).
LL_ADC_REG_TRIG_EXT_TIM5_CH1
ADC group regular conversion trigger from
external IP: TIM5 channel 1 event (capture
compare: input capture or output capture).
Trigger edge set to rising edge (default
setting).
LL_ADC_REG_TRIG_EXT_TIM5_CH2
ADC group regular conversion trigger from
external IP: TIM5 channel 2 event (capture
compare: input capture or output capture).
Trigger edge set to rising edge (default
setting).
LL_ADC_REG_TRIG_EXT_TIM5_CH3
ADC group regular conversion trigger from
external IP: TIM5 channel 3 event (capture
compare: input capture or output capture).
Trigger edge set to rising edge (default
setting).
LL_ADC_REG_TRIG_EXT_TIM8_CH1
ADC group regular conversion trigger from
external IP: TIM8 channel 1 event (capture
compare: input capture or output capture).
Trigger edge set to rising edge (default
setting).
LL_ADC_REG_TRIG_EXT_TIM8_TRGO
ADC group regular conversion trigger from
external IP: TIM8 TRGO. Trigger edge set to
rising edge (default setting).
LL_ADC_REG_TRIG_EXT_EXTI_LINE11
ADC group regular conversion trigger from
external IP: external interrupt line 11. Trigger
edge set to rising edge (default setting).
ADC instance - Resolution
LL_ADC_RESOLUTION_12B
ADC resolution 12 bits
LL_ADC_RESOLUTION_10B
ADC resolution 10 bits
LL_ADC_RESOLUTION_8B
ADC resolution 8 bits
LL_ADC_RESOLUTION_6B
ADC resolution 6 bits
ADC instance - Scan selection
LL_ADC_SEQ_SCAN_DISABLE
ADC conversion is performed in unitary conversion
mode (one channel converted, that defined in rank 1).
Configuration of both groups regular and injected
sequencers (sequence length, ...) is discarded:
equivalent to length of 1 rank.
LL_ADC_SEQ_SCAN_ENABLE
ADC conversions are performed in sequence
conversions mode, according to configuration of both
groups regular and injected sequencers (sequence
length, ...).
ADC helper macro
__LL_ADC_CHANNEL_TO_DECI
MAL_NB
Description:
Helper macro to get ADC channel number in
decimal format from literals
