Operation 5
Commissioning
Checking the emergency stop
function
WARNING
No electric brake assistance when the emergency
off switch is actuated!
Actuating the emergency off switch will disconnect
the drives from the power supply.
– To brake, actuate the service brake.
– Slowly drive the truck forwards.
6321_003-145
F1
F2
1
IV
I
III
II
F1
F2
1
1
1
– Press the emergency off switch (1).
Thetruckwillrolltoastop.
The display and operating unit shows the
message
EMERGENCY SWITCH periodically.
– Brake the truck to a standstill by depressing
the brake pedal.
– Pull out/turn the emergency off switch (1).
The truck performs an internal self-test and is
then ready for operation again.
Zero adjustment of the load mea-
surement (variant)
NOTE
A zero adjustment must be carried out in
order to guarantee the accuracy of the load
55
048011501 EN - 12/2015 101
