Definition of directions
The directions "forwards" (1), "backwards" (3),
"right" (2) and "left" (4) refer to the installation
position of the parts as seen from the driver’s
compartment; the load is to the front.
Schematic views
6210_003-062
View of functions and operations
This documentati
on explains the (usually
sequential) cha
in of certain functions or oper-
ations. Schemat
ic diagrams of a counterbal-
ance truck are us
ed to illustrate these proce-
dures.
NOTE
These schemati
c diagrams are not represen-
tative of the s
tructural state of the documented
truck. The dia
grams are used solely for the
purpose of cla
rifying procedures.
