5 Operation
Handling the battery
1
5060_003-051
– Disconnect the battery male connector (1)
by pulling in the direction of the arrow at the
plug connection.
– Place the battery male connector on the
battery.
CAUTION
There is a risk of short circuit if the
cables are damaged.
Position the battery cable on the
battery in such a way that it cannot
be crushed - either when removing or
inserting the battery, or when closing
the battery door.
– Check the connecting cable for
damage.
– Ensure that the battery cable does
not come into contact with the
battery door.
– Close the battery door.
Battery replacement using a bridge
Removing the battery
DANGER
WARNING
If the truck is not parked on horizontal
ground, there is nothing to prevent
thebatteryrollingawayoncethelock
has been opened, leading to a risk of
crushing and shearing!
– The truck must be parked on
horizontal ground.
– People must not stand directly in
the battery’s direction of travel or in
the battery compartment.
– Do not place objects or any parts
of the body between the battery
and the truck chassis.
– Use only the handles that are
provided and identified.
26
2 55048011501 EN - 12/2015
