Still RX50-13 - Controlling Attachments Using a Quadruple Mini-Lever

5 Operation
Working with attachments
5060_003-110
1
2
A
C
B
D
5060_003-109_V2
AC
B
D
Controlling attachments using a
quadruple mini-lever
The attachments (variant) are controlled in
this version using operating levers (1) and (2).
The pictograms on the operating levers show
the respective function that is activated by
these levers.
This essentially involve
s the following:
– Move the operating lever (1) towards (A)
The attachment moves in the direction shown
in pictogram (A).
– Move the operating leve
r(1)towards(B)
The attachment moves in the direction shown
in pictogram (B).
– Move the operating lever (2) towards (C)
The attachment moves in
the direction shown
in pictogram (C).
– Move the operating lever (2) towards (D)
The attachment moves in the direction shown
in pictogram (D).
