Still RX50-13 - VDI Datasheet: RX50-10 and RX50-13

Technical data 7
VDI datasheet: RX50-10 and RX50-13
NOTE
Measurements h
1
,h
3
,h
4
,h
6
and
b
1
are
customer-specific and can be ta
ken from the
order confirmation.
Centre of gravity position — centre of gravity
"S"(Distance measured from the front axle)
RX50-10c 576 mm
RX50-10 592 mm
RX50-13 663 mm
RX50-15 720 mm
RX50-16 717 mm
NOTE
The specified centre of gravity "S" relates
to trucks with standard equipment. If, for
example, the truck is equipped with a different
lift mast, attachment or driver protection
structure, this value is only a guide value. If
necessary, the centre of gravity "S" must be
determined on an individual basis for each
truck.
VDI datasheet: RX50-10 and
RX50-13
Characteristics
Model
RX50-10c RX50-10 RX50-13
Type number
5060 5061 5063
Manufacturer STILL GmbH STILL GmbH STILL GmbH
Drive
Electric Electric Electric
Operation
Seated Seated Seated
Rated capacity/load
Q(kg)
1000 1000 1250
Load centre of gravity distance c (mm)
500 500 500
Load distance
x (mm)
330 330 330
Wheelbase
y (mm)
974 1028 1136
.
