7 Technical data
VDI datasheet: RX50-10 and RX50-13
Weight
Model
RX50-10c RX50-10 RX50-13
Type number
5060 5061 5063
Net weight including battery kg
2358 2372 2561
Front axle load with load
kg
2833 2832 3247
Rear axle load with load
kg
525 540 564
Front axle load without
load
kg
981 1025 1084
Rear axle load without l
oad
kg
1377 1347 1477
.
Wheels, chassis frame
Model
RX50-10c RX50-10 RX50-13
Type number
5060 5061 5063
Tyres
Superelastic Superelastic Superelastic
Front tyre size
180/70-8 180/70-8 180/70-8
Rear tyre size
180/70-8 180/70-8 180/70-8
Number of front wheels (x = driven)
222
Number of rear wheels (x = driven)
1x 1x 1x
Front track width
b
10
(mm)
840 840 840
Rear track width
b
11
(mm)
———
.
Basic dimensions
Model
RX50-10c RX50-10 RX50-13
Type number
5060 5061 5063
Tilt of lift mast/fork carriage,
forwards
α (degrees)
333
Tilt of lift mast/fork carriage,
backwards
β (degrees)
555
Height with lift mast retracted h
1
(mm)
2160 2160 2160
Free lift
h
2
(mm)
150 150 150
Lift
1
h
3
(mm)
3230 3230 3230
Height with lift mast extended h
4
(mm)
3805 3805 3805
1
The specified lift takes into account the tyre deflection and the tolerances ofthetyrediameter.
