Technical data 7
VDI datasheet: RX50-10 and RX50-13
Model RX50-10c RX50-10 RX50-13
Type number
5060 5061 5063
Height to top of overhead guard
(cab)
h
6
(mm)
1980 1980 2050
Seat height (in relation to S
IP)
h
7
(mm)
953 953 953
Coupling height h
10
(mm)
—— —
Total length l
1
(mm)
2359 2413 2521
Length including fork back l
2
(mm)
1559 1613 1721
Total width
b
1
(mm)
990 990 990
Fork arm thickness
s (mm)
40 40 40
Fork arm width
e(mm)
80 80 80
Fork arm length
l (mm)
800 800 800
Fork carriage according to
ISO 2328, class/form A, B
ISO II/A ISO II/A ISO II/A
Fork carriage wi
dth
b
3
(mm)
980 980 980
Ground clearance with load under
lift mast
m
1
(mm)
90 90 90
Ground clearance at centre of
wheelbase
m
2
(mm)
90 90 90
Aisle width for pallet 1000 x 1200
crosswise
A
st
(mm)
2888 2942 3050
Aisle width for pallet 800 x 1200
longitudinal
A
st
(mm)
3010 3064 3172
Turning radius
W
a
(mm)
1229 1283 1391
Smallest pivot point distance b
13
(mm)
—— —
.
Performance data
Model
RX50-10c RX50-10 RX50-13
Type number
5060 5061 5063
Driving speed with load
km/h 12.0 12.0 12.0
Driving speed without load
km/h 12.5 12.5 12.5
Lifting speed with load
m/s 0.38 0.38 0.33
Lifting speed without load
m/s 0.54 0.54 0.54
Lowering speed with load
m/s 0.54 0.54 0.54
Lowering speed without load
m/s 0.60 0.60 0.60
55
048011501 EN - 12/2015 341
