5 Operation
Driving
Driveways
Dimensions of the driveways and aisle
widths
The following dimensions and aisle width
requirements apply under the specified con-
ditions to ensure safe manoeuvring. In each
case, it should be checked whether a larger
aisle width is necessary, e.g. with deviating
load dimensions. Within the EU, there must
be compliance with the 89/654/EEC directive
(minimum safety and health requirements
for the workplace). The respective national
guidelines apply for the areas outside of the
EU.
The required aisle widths
depend on the
dimensions of the load.
For pallets, these are:
Aisle width [mm]
Model
Type
With pallet
1000x1200
crosswise
With pallet
800x1200
lengthwise
RX50-10
compact
5060 2888 3010
RX50-10 5061 2942 3064
RX50-13 5063 3050 3172
RX50-15 5065 3104 3226
RX50-16 5066 3109 3231
The truck may only be used on driveways that
do not have curves that are too tight, have
gradients that are too steep, and entrances
that are not too narrow or low.
Driving on gradients
WARNING
Driving up and down long gradients may cause the
drive unit to overheat and switch off.
It is not permitted to drive up and down long gra-
dients due to the minimum specified braking va-
lues. The climbing capability values given below
only apply to overcoming obstacles on the roadway
and to short differences in level, e.g. ramps.
10
6 55048011501 EN - 12/2015
