Operation 5
Lifting
Lifting
Lifting system variants
The movement of the fork carriage and the
lift mast heavily depends on the following
equipment:
• The lift mast with which the truck is
equipped, see ⇒ Chapter "Types of lift
mast", P. 5-128
• The operating device with w
hich the
hydraulic functions are co
ntrolled, see
⇒ Chapter "Lifting system o
perating de-
vices", P. 5-131
Regardless of the equipment variants of the
truck, the basic specifications and procedures
must be complied with, see ⇒ Chapter "Safety
regulations when handing loads", P. 5-147.
Automatic lift cut out (variant)
Description:
The automatic lift cut out (variant) means that
the load cannot be lifted above a preset height.
This function uses a sensor that is welded on
at the factory at the required lift mast limit
height. Once attached, the height cannot be
easily changed.
Application:
• If the ceiling of the
building is lower than
the maximum lift hei
ght of the truck, this
variant can prevent
the lift mast from
accidentally hitti
ng the ceiling, which can
result in damage.
• If the truck is frequently used at a particular
height, the work is simplified by the auto-
matic lift cut out at this height.
NOTE
If a load is lifte
d very quickly, the fork carriage
and load are move
d approximately 15 cm
above the positi
on of the sensor due to
inertia. This de
viation is already taken into
consideration a
t the factory when determining
the position of t
he sensor.
55
048011501 EN - 12/2015 123
