Operation 5
Workingwithattachments
General instructions for controlling
attachments
The way in which attachments (variant) are
controlled depends on the operating devices
included in the truck’s equipment.
Essentially, a distinction is drawn between:
• Multiple-lever
• Multiple-lever with a 5th f
unction (variant)
• Double mini-lever
• Double mini-lever with a 5th function
(variant)
• Triple mini-lever
• Triple mini-lever with a 5th function (variant)
• Quadruple mini-lever
• Quadruple mini-lever wi
th a 5th function
(variant)
• Joystick 4Plus
• Joystick 4Plus with a 5th function (variant)
• Fingertip
• Fingertip with a 5th function (variant)
– For information on controlling attachments
with the respective operating devices, see
the relevant sections in this chapter.
WARNING
Use of attachments can give rise to additional
hazards such as a change in the centre of gravity,
additional danger areas etc.
Attachments must only be used for their intended
purpose as described in the relevant operating
instructions. Drivers must be taught how to operate
the attachments.
Loads may only be picked up and transported
with attachments if they are securely grasped and
attached. Where necessary, loads must also be
secured against slipping, rolling away, falling over,
swinging or tipping over. Note that any change to
the position of the load centre of gravity will affect
the stability of the truck.
– Refer to the capacity rating plate for the attach-
ments being used.
NOTE
Further variants and functions are available in
addition to the functions described below. The
