5 Operation
Working with attachments
1
F1
F2
1
1
F1
F2
1
1
6311_003-034_V2
Releasing pressure, joystick 4Plus,
mini-lever and fingertip switch
NOTE
In trucks with the "FleetManager" or "access
authorisation with PIN code" equipment va-
riants, access authorisation must be enabled.
– Switch on the key switch.
– Lower the fork carriage.
– Switch on the hazard warning system
(variant).
NOTE
Press the button for switching on the hazard
warning system even if the truck is not equip-
ped with a hazard warning system. Switching
on the hazard warning system prevents the
electrical system from being switched off,
even if the key switch is subsequently swit-
ched off.
– Switch off the key switch.
– Actuate the operating lever (1) for control-
ling the hydraulic functions repeatedly in
the direction of the arrow, as far as the end
position.
The valves open and the hydraulic system is
depressurised.
16
8 55048011501 EN - 12/2015
