6 Maintenance
Safety regulations for maintenanc
e
Working at the front of the truck
DANGER
Risk of accident!
If the lift mast or fork carriage is raised, no work
may be performed on the lift mast or at the front of
the truck unless the following safety measures are
observed.
– When securing, only use chains with sufficient
load-bearing capacity.
– Contact the authorised service centre.
CAUTION
Possibility of damage to the ceiling!
– Notethemaximumliftheightoftheliftmast.
Securing the lift mast against tilting
backwards
A hardwood beam with a cross-section of
120 x 120 mm is required. The length of
the hardwood beam must approximately
correspond to the width of the fork carriage
(b3). To avoid impact injuries, the hardwood
beam must not protrude beyond the outer
contour of the truck. A maximum length
matching the total width (b1) of the truck is
recommended.
– Obtain the dimensions (b1) and (b3) from
the corresponding VDI datasheet.
30
8 55048011501 EN - 12/2015
