Still RX50-13 - General View of Drivers Compartment

4 Overviews
General view of driver’s compartme
nt
General view of driver’s compartment
4
1
2
34
5
6
7
8
9
10
11
12
13
14
15
5060_003-093_V2
1 Parking brake lever
2 Steering wheel
3Switchkey
4 Display operating unit
5 Document holder and storage location for
operating instructions
6 Operating devices for hydraulic and traction
functions
7 Emergency stop switch (only in multiple-
lever version)
8 Storage box
9 Cup holder for bottles max. 1 l
10 Battery hood handle
11 Battery hood release
12 Driver’s seat
13 Accelerator pedal
14 Brake pedal
15 Signal horn foot switch
52
55048011501 EN - 12/2015
