7 Technical data
VDI datasheet: RX50-10 and RX50-13
Model RX50-10c RX50-10 RX50-13
Type number
5060 5061 5063
Pulling force with load
N 1650 1650 1400
Pulling force without load
N 1950 1950 1700
Max. pulling force without load
N 2840 2840 3500
Max. pulling force without load
N 7150 7150 7150
Climbing capability with load
%
6.5 6.5 5.0
Climbing capability without load
% 11.0 11.0 8.5
Max. climbing capability with load
%
19.0 19.0 19.0
Max. climbing capability without
load
% 25.0 25.0 25.0
Acceleration time
with load
s
5.1 5.1 5.3
Acceleration time
without load
s
4.7 4.7 4.8
Service brake
Hydraulic Hydraulic Hydraulic
.
Elec. motor
Model
RX50-10c RX50-10 RX50-13
Type number
5060 5061 5063
Traction moto
r, power rating at S2:
60 min.
kW
4.9 4.9 4.9
Lift motor, power rating at S3: 15%
kW 7.6 7.6 7.6
Battery in accordance with DIN
43531/35/36 A, B, C, no
DIN 43535 A DIN 43535 A DIN 43535 A
Battery voltage
U(V)
24 24 24
Battery capacity
K
5
(Ah)
460
575
805
Battery weight kg 372 445 600
Energy consumption: 60 VDI
working cycles/hour
kWh/h 3.7 3.7 4.2
.
Other
Model
RX50
-10c
RX50
-10
RX50
-13
Type number
5060 5061 5063
Working pressure for attachments
bar 230 230 230
Oil
flow for attachments
l/min
30 30 30
34
