Operation 5
Lifting
CAUTION
Risk of damage to property due to the lift mast
colliding with racks or other objects!
– Before using the "lift mast vertical position"
comfort feature, position the truck at a sufficient
distance from racks and other objects.
The "lift mast vertical position" comfort feature
consists of the following individual functions:
• Display of the "lift mast vertical position"
• Automatic approach towards the "lift mast
vertical position"
• Gentle running-in to the end stops
F
1
F2
F
1
F2
6210_003-092
1
2
45
3
The "lift mast vertical position" comfort feature
is only available as a variant if the truck is
equipped with one of the following operating
devices:
• Double mini-lever (1)
• Triple mini-lever (2)
• Quadruple mini-lever (3)
• Fingertip (4)
• Joystick 4Plus (5)
55
048011501 EN - 12/2015 125
