5 Operation
Working with loads
– Attach or secure the load to the lifting
accessory so that the load cannot move
or fall.
– Store the load so that the specified aisle
width is not reduced by protruding parts.
6210_800-005
– Approach the rack carefully, b
rake gently
and stop just in front of the r
ack.
6210_800-006
– Position the fork
s.
NOTE
The tilt speed of
theliftmastinthistruckis
significantly hi
gher than for previous products
in this series. T
hisissignalledbyawarning
message shown on
the display and operating
unit after the ke
y switch has been switched on.
– Set the lift mast to vertical.
– Lift the fork carriage to the stacking height.
CAUTION
Risk of component damage!
When inserting the fork into the rack, ensure that
the rack and load are not damaged.
15
6 55048011501 EN - 12/2015
