Operation 5
Workingwithattachments
5060_003-167
23
6
4
7
5
8
– Note the following attachment functions and
pictograms.
2
Move side shift frame or fork for-
wards/backwards
3
Move sideshift to the left/ri
ght
4
Adjust fork arms: open/clo
se
5
Push off/pull in load
6
Turn to the left/right
7
Tip shovel over/tip shov
el back
8
Swivel lift mast or fork
to the left/right
NOTE
The pictograms shown correspond to the
attachments fitted to this truck at the factory. If
an attachment with other functions is fitted, the
pictograms must be checked for the correct
representation and changed if necessary.
– Contact the authoris
ed service centre if
required.
55
048011501 EN - 12/2015 173
