Operation 5
Workingwithattachments
5060_003-122
3
4
1
2
– Note the following attachment functions and
pictograms.
1
Adjust fork arms: open
2
Adjust fork arms: close
3
Rotate to the left
4
Rotate to the right
NOTE
The pictograms shown correspond to the
attachments fitted to this truck at the factory. If
an attachment with other functions is fitted, the
pictograms must be checked for the correct
representation and changed if necessary.
– Contact the authorised s
ervice centre if
required.
