6 Maintenance
Maintenance
5060_003-158
1
– Open the cover (1).
– Remove the cover from the control electron-
ics.
5060_003-159
3
3
2
– Locate the blown fuse; see the section
entitled "Fuse assignment".
– Unscrew the faulty fuse (2) or remove the
faulty fuse (3) and replace it with a new fuse
with the specified nominal current.
CAUTION
Water in the electrical system can
cause damage to components!
In order to protect the electrical
system against ingress of water, the
cover must be closed.
– Refit the cover after completion of
the activities.
– Close the cover of the control electronics.
– Close the cover.
– Close the battery hood.
– Connect the battery male connector.
– Carry out a functional test.
32
8 55048011501 EN - 12/2015
