21.Safety Configuration
21.1. Safety Settings Basics
This section covers how to access the robot safety settings. It is made up of items that help you
set up the robot Safety Configuration.
WARNING
Before you configure your robot safety settings, your integrator must conduct a risk
assessment to guarantee the safety of personnel and equipment around the robot.
A risk assessment is an evaluation of all work procedures throughout the robot
lifetime, conducted in order to apply correct safety configuration settings
(seeHardware Installation Manual ). You must set the following in
accordance with the integrator’s risk assessment.
1. The integrator must prevent unauthorized persons from changing the safety
configuration e.g. installing password protection.
2. Use and configuration of the safety-related functions and interfaces for a
specific robot application (seeHardware Installation Manual ).
3. Safety configuration settings for set-up and teaching before the robot arm is
powered on for the first time.
4. All safety configuration settings accessible on this screen and sub-tabs.
5. The integrator must ensure that all changes to the safety configuration
settings comply with the risk assessment.
21.1.1. Accessing Safety Configuration
Note: Safety Settings are password protected and can only be configured once a password is set
and subsequently used.
1. In your PolyScope header, tap the Installation icon.
2. In the Side Menu on the left of the screen, tap Safety.
3. Observe that the Robot Limits screen displays, but settings are inaccessible.
4. If a Safety password was previously set, enter the password and press Unlock to make
settings accessible. Note: Once Safety settings are unlocked, all settings are now active.
5. Press Lock tab or navigate away from the Safety menu to lock all Safety item settings again.
User Manual 119 UR5e
21.Safety Configuration
Copyright © 2009–2021 by UniversalRobotsA/S. All rights reserved.
