24.19.13. Show Advanced Options
This check box shows/hides the advanced options for each signal.
24.19.14. Advanced Options
Update Frequency
This menu can be used to change the update frequency of the signal. This means the
frequency with which requests are sent to the remote MODBUS unit for either reading or writing
the signal value. When the frequency is set to 0, then modbus requests are initiated on demand
using a modbus_get_signal_status, modbus_set_output_register, and modbus_set_output_signal
script functions.
Slave Address
This text field can be used to set a specific slave address for the requests corresponding to a
specific signal. The value must be in the range 0-255 both included, and the default is 255. If
you change this value, it is recommended to consult the manual of the remote MODBUS device
to verify its functionality when changing slave address.
Reconnect count
Number of times TCP connection was closed, and connected again.
Connection status
TCP connection status.
Response time [ms]
Time between modbus request sent, and response received - this is updated only when
communication is active.
Modbus packet errors
Number of received packets that contained errors (i.e. invalid length, missing data, TCP socket
error).
Timeouts
Number of modbus requests that didn’t get response.
Requests failed
Number of packets that could not be sent due to invalid socket status.
Actual freq.
The average frequency of client (master) signal status updates. This value is recalculated each
time the signal receives a response from the server (or slave).
All counters count up to 65535, and then wrap back to 0.
24.20. EtherNet/IP
EtherNet/IP is a network protocol that enables the connection of the robot to an industrial
EtherNet/IP Scanner Device.
If the connection is enabled, you can select the action that occurs when a program loses
EtherNet/IP Scanner Device connection.
UR5e 236 User Manual
24.Installation Tab
Copyright © 2009–2021 by UniversalRobotsA/S. All rights reserved.
