YASKAWA manufactures products used as components in a wide variety of industrial systems and equipment. The
selection and application of YASKAWA products remain the responsibility of the equipment manufacturer or end user.
YASKAWA accepts no responsibility for the way its products are incorporated into the final system design. Under no
circumstances should any YASKAWA product be incorporated into any product or design as the exclusive or sole safety
control. Without exception, all controls should be designed to detect faults dynamically and fail safely under all
circumstances. All systems or equipment designed to incorporate a product manufactured by YASKAWA must be
supplied to the end user with appropriate warnings and instructions as to the safe use and operation of that part. Any
warnings provided by YASKAWA must be promptly provided to the end user. YASKAWA offers an express warranty
only as to the quality of its products in conforming to standards and specifications published in the YASKAWA manual.
NO OTHER WARRANTY, EXPRESS OR IMPLIED, IS OFFERED. YASKAWA assumes no liability for any personal
injury, property damage, losses, or claims arising from misapplication of its products.
This manual is designed to ensure correct and suitable applicat
ion of Variable A1000-Series Drives. Read this manual
before attempting to install, operate, maintain, or inspect a drive and keep it in a safe, convenient location for future
reference. Be sure you understand all precautions and safety information before attempting application.
Applicable Documentation
The following manuals are available for A1000 series drives:
Symbols
Note: Indicates a supplement or precaution that does not cause drive damage.
Terms and Abbreviations
Trademarks
• CANopen is a trademark of CAN in Automation (CiA).
• CC-Link is a trademark of CC-Link Partner Association (CLPA).
• DeviceNet is a trademark of Open DeviceN
et Vendor Association, Inc. (ODVA).
• PROFIBUS-DP is a trademark of PROFIBUS International (PI).
• MECHATROLINK-I, MECHATROLINK-II, and MECHATROLINK-III
are a trademark of MECHATROLINK
Members Association (MMA).
• LONWORKS is a trademark of ECHELON USA.
• Modbus TCP/IP is a trademark of Modbus-IDA.
• EtherNet/IP is a trademark of the ODVA.
• Other companies and product names mentioned in this
manual are trademarks of those companies.
A1000 Series AC Drive Quick Start Guide
This guide is packaged together with the product. It contains basic information on safety precautions, model list, and wiring. It is
meant to get the drive ready for a trial run with the application and for basic operation.
A1000 Series AC Drive Technical Manual (this book)
This manual is included on the CD-ROM packaged with the product (YASKAWA AC Drive Manuals, TOBC C710616 21). The
manual contains information required to install and wire the drive, in addition to an overview of fault diagnostics, maintenance
safety, and parameter settings. Contact a YASKAWA representative to obtain the manual. The manual is also available for
download on our documentation website, e-mechatronics.com.
: Indicates a term or definition used in this manual.
• Drive: YASKAWA A1000 Series Drive
• V/f: V/f Control
• V/f w/PG: V/f Control with PG
• OLV: Open Loop Vector Control
• CLV: Closed Loop Vector Control
• OLV/PM: Open Loop Vector Control for PM
• AOLV/PM: Advanced Open Loop Vector Control for PM
• CLV/PM: Closed Loop Vector Control for PM
• PM motor: Permanent Magnet Synchronous motor (an abbreviation for IPM motor or SPM motor)
• IPM motor: Interior Permanent Magnet Motor (such as YASKAWA’s SSR1 Series and SST4 Series motors)
• SPM motor: Surface mounted Permanent Magnet Motor (such as YASKAWA’s SMRA Series motors)
CIMR-AA2A0021FAA
