E.1 Drive and Motor Specifications
E.1 Drive and Motor Specifications
 Drive Specifications
 Motor Specifications
 Induction Motor
 Permanent Magnet Motor
 Motor Speed Encoder (if used)
Items Value
Model CIMR-A
Serial Number
Software Version (PRG)
Options used 
(Option cards, braking transistor,etc.)
Items Value Items Value
Manufacturer Motor Rated Current A
Model Motor Base Frequency Hz
Motor Rated Power kW Number of Motor Poles
Motor Rated Voltage V Motor Rated Speed (T1-07)
min
-1
Items Value Items Value
Manufacturer Induction Voltage Constant mVs/rad
Model Induction Voltage Constant
mV/(min
-1
)
PM Motor Rated Power kW PM Motor Rated Current A
PM Motor Rated Voltage V PM Motor Base Frequency Hz
d-Axis Inductance mH Number of PM Motor Poles
q-Axis Inductance mH PM Motor Base Speed
min
-1
Items Value Items Value
Manufacturer Resolution
Interface
PRG : 1010
GI-COMPLIANT
IND.CONT.EQ.
7J48
CIMR-AC2A0110AAA
MADE IN JAPAN
:
: AC3PH 200-240V 50/60Hz 111A/82A
: AC3PH 0-240V 0-400Hz 110A/85A
: 21 kg
:
:
: E131457 IP00
PASS
MODEL
MAX APPLI. MOTOR : 30kW / 22kW REV : B
INPUT
OUTPUT
MASS
O / N
S / N
FILE NO
TYPE 1 ENCLOSURE
YASKAWA ELECTRIC CORPORATION
2-1 Kurosaki-shiroishi, Yahatanishi-Ku, Kitakyushu 806-0004 Japan
AC drive model
Input specifications
Output specifications
Lot number
Serial number
Software version
Enclosure type
Normal Duty Amps / Heavy Duty Amps
