1.3 Model Number and Nameplate Check
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 33
Three-Phase 200 V
Table 1.3 Model Number and Specifications (200 V)
Three-Phase 400 V
Table 1.4 Model Number and Specifications (400 V)
Note: 1. Set C6-01 to select Normal duty and Heavy duty (default).
2. Refer to Drive Models and Enclosure T
ypes on page 34 for differences regarding enclosure protection types and component
descriptions.
Heavy Duty (HD)
[C6-01 = 0]
Normal Duty (ND)
[C6-01 = 1]
No. Max. Motor Capacity kW Rated Output Current A No. Max. Motor Capacity kW Rated Output Current A
0004 0.55 3.2 0004 0.75 3.5
0006 0.75 5 0006 1.5 6.0
0010 1.5 8 0010 2.2 9.6
0012 2.2 11 0012 3.0 12
0021 4.0 17.5 0021 5.5 21
0030 5.5 25 0030 7.5 30
0040 7.5 33 0040 11 40
0056 11 47 0056 15 56
0069 15 60 0069 18.5 69
0081 18.5 75 0081 22 81
0110 22 85 0110 30 110
0138 30 115 0138 37 138
0169 37 145 0169 45 169
0211 45 180 0211 55 211
0250 55 215 0250 75 250
0312 75 283 0312 90 312
0360 90 346 0360 110 360
0415 110 415 0415 110 415
Heavy Duty (HD)
[C6-01 = 0]
Normal Duty (ND)
[C6-01 = 1]
No. Max. Motor Capacity kW Rated Output Current A No. Max. Motor Capacity kW Rated Output Current A
0002 0.55 1.8 0002 0.75 2.1
0004 1.1 3.4 0004 1.5 4.1
0005 1.5 4.8 0005 2.2 5.4
0007 2.2 5.5 0007 3.0 6.9
0009 3.0 7.2 0009 4.0 8.8
0011 4.0 9.2 0011 5.5 11.1
0018 5.5 14.8 0018 7.5 17.5
0023 7.5 18 0023 11 23
0031 11 24 0031 15 31
0038 15 31 0038 18.5 38
0044 18.5 39 0044 22 44
0058 22 45 0058 30 58
0072 30 60 0072 37 72
0088 37 75 0088 45 88
0103 45 91 0103 55 103
0139 55 112 0139 75 139
0165 75 150 0165 90 165
0208 90 180 0208 110 208
0250 110 216 0250 132 250
0296 132 260 0296 160 296
0362 160 304 0362 185 362
0414 185 370 0414 220 414
0515 220
450 0515 250 515
0675 315 605 0675 355 675
0930 450 810 0930 500 930
1200 560 1090 1200 630 1200
