8.5 Installing Peripheral Devices
434 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
Installing Input Fuses
NOTICE: If a fuse is blown or an equipment for residual current monitoring/detection (RCM/RCD) tripped, check the wiring and the
selection of the peripheral devices to identify the cause. Contact YASKAWA before restarting the drive or the peripheral devices if the
cause cannot be identified.
YASKAWA recommends installing a fuse on the input side of the drive to prevent damage to the drive if a short circuit
occurs.
Select the appropriate fuse from Table 8.12.
Table 8.12 Input Fuses
Note: Model CIMR-A4A1200 is UL compliant when the air entering the drive-installed panel or cabinet is 45C or less. For more
information, contact your nearest YASKAWA representative or our sales office.
Attachment for External Heatsink (IP00 Enclosure)
An external heatsink can be attached that projects outside the enclosure. Steps should be taken to ensure that there is
enough air circulation around the heatsink.
Contact your YASKAWA sales representative or YASKAWA directly.
EMC Filter Installation
This drive is tested according to European standards IEC/EN 61800-5-1 and complies with the EMC guidelines. Refer to
EMC Filter Installation on page 580 for details about EMC filter selection and install
ation.
Model
CIMR-A
Fuse Type
Model
CIMR-A
Fuse Type
Manufacturer: Bussmann Manufacturer: Bussmann
Model Fuse Ampere Rating Model Fuse Ampere Rating
Three-Phase 200 V Class Three-Phase 400 V Class
2A0004 FWH-70B 70 4A0002 FWH-40B 40
2A0006 FWH-70B 70 4A0004 FWH-50B 50
2A0010 FWH-70B 70 4A0005 FWH-70B 70
2A0012 FWH-70B 70 4A0007 FWH-70B 70
2A0021 FWH-90B 90 4A0009 FWH-90B 90
2A0030 FWH-100B 100 4A0011 FWH-90B 90
2A0040 FWH-200B 200 4A0018 FWH-80B 80
2A0056 FWH-200B 200 4A0023 FWH-100B 100
2A0069 FWH-200B 200 4A0031 FWH-125B 125
2A0081 FWH-300A 300 4A0038 FWH-200B 200
2A0110 FWH-300A 300 4A0044 FWH-250A 250
2A0138 FWH-350A 350 4A0058 FWH-250A 250
2A0169 FWH-400A 400 4A0072 FWH-250A 250
2A0211 FWH-400A 400 4A0088 FWH-250A 250
2A0250 FWH-600A 600 4A0103 FWH-250A 250
2A0312 FWH-700A 700 4A0139 FWH-350A 350
2A0360 FWH-800A 800 4A0165 FWH-400A 400
2A0415 FWH-1000A 1000 4A0208 FWH-500A 500
– – – 4A0250 FWH-600A 600
– – – 4A0296 FWH-700A 700
– – – 4A0362 FWH-800A 800
– – – 4A0414 FWH-800A 800
– – – 4A0515 FWH-1000A 1000
– – – 4A0675 FWH-1200A 1200
– – – 4A0930 FWH-1200A 1200
– – – 4A1200 FWH-1600A 1600
