YASKAWA A1000 Technical Manual

B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 507
Parameter List
B
 q: DriveWorksEZ Parameters
 r: DriveWorksEZ Connection Parameters
 T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal performance

T1: Induction Motor Auto-Tuning
o4-07
(523H)
DC Bus Pre-Charge Relay
Maintenance Setting
Sets the point at which the cumulative timing for the soft charge bypass relay maintenance
starts. View monitor U4-06 to determine when the bypass relay may require replacement.
Default: 0%
Min: 0%
Max: 150%
319
o4-09
(525H)
IGBT Maintenance Setting
Sets the point at which the cumulative timing for the IGBTs maintenance starts.
View monitor U4-07 to determine when the IGBTs may require replacement.
Default: 0%
Min: 0%
Max: 150%
319
o4-11
(510H)
U2, U3 Initialization
0: U2- and U3- monitor data is not reset when the drive is initialized (A1-03).
1: U2- and U3- monitor data is reset when the drive is initialized (A1-03). (The value
of o4-11 is automatically returned to 0.)
Default: 0
Min: 0
Max: 1
319
o4-12
(512H)
kWh Monitor Initialization
0: U4-10 and U4-11 monitor data is not reset when the drive is initialized (A1-03).
1: U4-10 and U4-11 monitor data is reset when the drive is initialized (A1-03). (The value of
o4-12 is automatically returned to 0.)
Default: 0
Min: 0
Max: 1
320
o4-13
(528H)
Number of Run Commands
Counter Initialization
0: U4-02 monitor data is not reset when the drive is initialized (A1-03).
1: U4-02 monitor data is reset when the drive is initialized (A1-03). (The value of o4-13 is
automatically returned to 0.)
Default: 0
Min: 0
Max: 1
320
No. (Addr.) Name Description Setting Page
q1-01 to
q6-07
(1600H to
1746H)
DriveWorksEZ Parameters
Reserved for DriveWorksEZ
Refer to Help in the
DWEZ software.
320
No. (Addr.) Name Description Setting Page
r1-01 to
r1-40
(1840H to
1867H)
DriveWorksEZ Connection
Parameters 1 to 20 (upper/lower)
DriveWorksEZ Connection Parameters 1 to 20 (upper/lower)
Default: 0
Min: 0
Max: FFFF
320
No. (Addr.) Name Description Setting Page
T1-00
(700H)
Motor 1/Motor 2 Selection
1: Motor 1 (sets E1-, E2-)
2: Motor 2 (sets E3-, E4-)
Default: 1
Min: 1
Max: 2
127
T1-01
(701H)
<37>
Auto-Tuning Mode Selection
0: Rotational Auto-Tuning
1: Stationary Auto-Tuning 1
2: Stationary Auto-Tuning for Line-to-Line Resistance
3: Rotational Auto-Tuning for V/f Control (necessary for Energy Savings and Speed Estimation
Speed Search)
4: Stationary Auto-Tuning 2
5: Stationary Auto-Tuning 3
8: Inertia Tuning (perform Rotational Auto-Tuning prior to Inertia Tuning)
9: ASR Gain Tuning (perform Rotational Auto-Tuning prior to ASR Gain Auto-Tuning)
Note 1. Stationary Auto-Tuning 3 is not available in models CIMR-A4A0930 and 4A1200.
2. Inertia Tuning and ASR Gain Auto-Tuning might not be available if gears are between
the machine and the motor shaft.
Default: 0
Min: 0
Max: 4, 5, 8, 9
<10>
128
T1-02
(702H)
Motor Rated Power
Sets the motor rated power as specified on the motor nameplate.
Default:
<9>
Min: 0.00 kW
Max: 650.00 kW
128
T1-03
(703H)
Motor Rated Voltage
Sets the motor rated voltage as specified on the motor nameplate.
Default: 200.0 V
<18>
Min: 0.0 V
Max: 255.0 V
<18>
128
No. (Addr.) Name Description Setting Page
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
