7.4 Cooling Fan and Circulation Fan
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 383
Periodic Inspection &
Maintenance
7
7.4 Cooling Fan and Circulation Fan
NOTICE: Follow cooling fan replacement instructions. The cooling fan cannot operate properly when installed incorrectly and could
seriously damage the drive. To ensure maximum useful product life, replace all cooling fans when performing maintenance.
Contact your YASKAWA representative or the nearest YASKAWA sales office to order replacement cooling fans as
required.
For drives with multiple cooling fans, replace all the fans
when performing maintenance to ensure maximum product
performance life.
Number of Fan
Three-Phase 200 V Class Three-Phase 400 V Class
Model
CIMR-A
Cooling Fan Circulation Fan Page
Model
CIMR-A
Cooling Fan Circulation Fan
Control Board
Cooling Fan
Page
2A0004 – – – 4A0002 – – – –
2A0006 – – – 4A0004 – – – –
2A0010 – – – 4A0005 – – – –
2A0012 – – – 4A0007 1 – –
385
2A0021 1 –
385
4A0009 1 – –
2A0030 2 – 4A0011 1 – –
2A0040 2 – 4A0018 2 – –
2A0056 2 – 4A0023 2 – –
2A0069 2 – 4A0031 2 – –
2A0081 2 – 4A0038 2 – –
2A0110 2 –
387
4A0044 2 – –
2A0138 2 – 4A0058 2 – –
387
2A0169 2 –
391
4A0072 2 – –
2A0211 2 – 4A0088 2 – –
389
2A0250 2 – 4A0103 2 – –
2A0312 2 – 4A0139 2 – –
391
2A0360 3 1 4A0165 2 – –
2A0415 3 1 4A0208 2 – –
– – – – 4A0250 3 – –
– – – – 4A0296 3 – –
– – – – 4A0362 3 1 –
– – – – 4A0414 3 1 – 395
– – – – 4A0515 3 2 2
397
– – – – 4A0675 3 2 2
– – – – 4A0930 6 4 4
400
– – – – 4A1200 6 4 4
