YASKAWA A1000 Technical Manual

B.3 Parameter Table
482 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
 H: Multi-Function Terminals
H parameters assign functions to the multi-function input and output terminals.

H1: Multi-Function Digital Inputs
F7-73
(78DH)
PZD4 Read
Sets MEMOBUS/Modbus address for PZD4 Read (PPO Read).
Values 0 disable the PZD4 Read.
Default: 0
Min: 0
Max: FFFF
–
F7-74
(78EH)
PZD5 Read
Sets MEMOBUS/Modbus address for PZD5 Read (PPO Read).
Values 0 disable the PZD5 Read.
Default: 0
Min: 0
Max: FFFF
–
F7-75
(78FH)
PZD6 Read
Sets MEMOBUS/Modbus address for PZD6 Read (PPO Read).
Values 0 disable the PZD6 Read.
Default: 0
Min: 0
Max: FFFF
–
F7-76
(790H)
PZD7 Read
Sets MEMOBUS/Modbus address for PZD7 Read (PPO Read).
Values 0 disable the PZD7 Read.
Default: 0
Min: 0
Max: FFFF
–
F7-77
(791H)
PZD8 Read
Sets MEMOBUS/Modbus address for PZD8 Read (PPO Read).
Values 0 disable the PZD8 Read.
Default: 0
Min: 0
Max: FFFF
–
F7-78
(792H)
PZD9 Read
Sets MEMOBUS/Modbus address for PZD9 Read (PPO Read).
Values 0 disable the PZD9 Read.
Default: 0
Min: 0
Max: FFFF
–
F7-79
(793H)
PZD10 Read
Sets MEMOBUS/Modbus address for PZD10 Read (PPO Read).
Values 0 disable the PZD10 Read.
Default: 0
Min: 0
Max: FFFF
–
<44> Cycle power for setting changes to take effect.
<45> If F7-13 is set to 0, then all IP Addresses (as defined with parameters F7-01 to F7-04) must be unique.
<46> Set F7-01 to F7-12 when F7-13 is set to 0.
<47> Set F7-15 when F7-14 is set to 0 or 2.
No.(Addr.) Name Description Setting Page
H1-01
(438H)
<31> Value in parenthesis is the default setting when a 3-wire initialization is performed (A1-03 = 3330).
Multi-Function Digital Input
Terminal S1 Function Selection
Assigns a function to the multi-function digital inputs.
Refer to H1 Multi-Function Digital Input Selections on page 483 for a description of setting
values.
Note: Unused terminals should be set to F.
Default: 40 (F)
<31>
Min: 1
Max: 9F
235
H1-02
(439H)
Multi-Function Digital Input
Terminal S2 Function Selection
Default: 41 (F)
<31>
Min: 1
Max: 9F
235
H1-03
(400H)
Multi-Function Digital Input
Terminal S3 Function Selection
Default: 24
Min: 0
Max: 9F
235
H1-04
(401H)
Multi-Function Digital Input
Terminal S4 Function Selection
Default: 14
Min: 0
Max: 9F
235
H1-05
(402H)
Multi-Function Digital Input
Terminal S5 Function Selection
Default: 3 (0)
<31>
Min: 0
Max: 9F
235
H1-06
(403H)
Multi-Function Digital Input
Terminal S6 Function Selection
Default: 4 (3)
<31>
Min: 0
Max: 9F
235
H1-07
(404H)
Multi-Function Digital Input
Terminal S7 Function Selection
Default: 6 (4)
<31>
Min: 0
Max: 9F
235
H1-08
(405H)
Multi-Function Digital Input
Terminal S8 Function Selection
Default: 8
Min: 0
Max: 9F
235
No.(Addr.) Name Description Setting Page
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes
All Modes

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
