B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 481
F7-17
(3F5H)
EtherNet/IP Speed Scaling Factor
Sets the scaling factor for the speed monitor in EtherNet/IP Class ID 2AH Object.
Default: 0
Min: -15
Max: 15
–
F7-18
(3F6H)
EtherNet/IP Current Scaling Factor
Sets the scaling factor for the output current monitor in EtherNet/IP Class ID 2AH Object.
Default: 0
Min: -15
Max: 15
–
F7-19
(3F7H)
EtherNet/IP Torque Scaling Factor
Sets the scaling factor for the torque monitor in EtherNet/IP Class ID 2AH Object.
Default: 0
Min: -15
Max: 15
–
F7-20
(3F8H)
EtherNet/IP Power Scaling Factor
Sets the scaling factor for the power monitor in EtherNet/IP Class ID 2AH Object.
Default: 0
Min: -15
Max: 15
–
F7-21
(3F9H)
EtherNet/IP Voltage Scaling Factor
Sets the scaling factor for the voltage monitor in EtherNet/IP Class ID 2AH Object.
Default: 0
Min: -15
Max: 15
–
F7-22
(3FAH)
EtherNet/IP Time Scaling
Sets the scaling factor for the time monitor in EtherNet/IP Class ID 2AH Object.
Default: 0
Min: -15
Max: 15
–
F7-23 to
F7-27
(3FBH to
3FFH)
F7-28 to
F7-32
(370H to
374H)
Dynamic Output Assembly
Parameters
Parameters used in Output Assembly 116. Each parameter contains a MEMOBUS/Modbus
address. The value received for Output Assembly 116 will be written to this corresponding
MEMOBUS/Modbus address. A MEMOBUS/Modbus address value of 0 means that the value
received for Output Assembly 116 will not be written to any MEMOBUS/Modbus register.
Default: 0 –
F7-33 to
F7-42
(375H to
37EH)
Dynamic Input Assembly
Parameters
Parameters used in Input Assembly 166. Each parameter contains a MEMOBUS/Modbus
address. The value sent for Input Assembly 166 will be read from this corresponding
MEMOBUS/Modbus address. A MEMOBUS/Modbus address value of 0 means that the value
sent for Input Assembly 166 is not defined by the user, therefore the option default register
value will be returned.
Refer to Ethernet/IP Technical Manual for definitions of the default MEMOBUS/Modbus
registers.
Default: 0 –
F7-60
(780H)
PZD1 Write
Sets MEMOBUS/Modbus address for PZD1 Write (PPO Write).
Values 0 to 2 enable the PZD1 Write as STW.
Default: 0
Min: 0
Max: FFFF
–
F7-61
(781H)
PZD2 Write
Sets MEMOBUS/Modbus address for PZD2 Write (PPO Write).
Values 0 to 2 enable the PZD2 Write as HSW.
Default: 0
Min: 0
Max: FFFF
–
F7-62
(782H
)
PZD3 Write
Sets MEMOBUS/Modbus address for PZD3 Write (PPO Write).
Values 0 to 2 disable the PZD3 Write.
Default: 0
Min: 0
Max: FFFF
–
F7-63
(783H)
PZD4 Write
Sets MEMOBUS/Modbus address for PZD4 Write (PPO Write).
Values 0 to 2 disable the PZD4 Write.
Default: 0
Min: 0
Max: FFFF
–
F7-64
(784H)
PZD5 Write
Sets MEMOBUS/Modbus address for PZD5 Write (PPO Write).
Values 0 to 2 disable the PZD5 Write.
Default: 0
Min: 0
Max: FFFF
–
F7-65
(785H)
PZD6 Write
Sets MEMOBUS/Modbus address for PZD6 Write (PPO Write).
Values 0 to 2 disable the PZD6 Write.
Default: 0
Min: 0
Max: FFFF
–
F7-66
(786H)
PZD7 Write
Sets MEMOBUS/Modbus address for PZD7 Write (PPO Write).
Values 0 to 2 disable the PZD7 Write.
Default: 0
Min: 0
Max: FFFF
–
F7-67
(787H)
PZD8 Write
Sets MEMOBUS/Modbus address for PZD8 Write (PPO Write).
Values 0 to 2 disable the PZD8 Write.
Default: 0
Min: 0
Max: FFFF
–
F7-68
(788H)
PZD9 Write
Sets MEMOBUS/Modbus address for PZD9 Write (PPO Write).
Values 0 to 2 disable the PZD9 Write.
Default: 0
Min: 0
Max: FFFF
–
F7-69
(789H)
PZD10 Write
Sets MEMOBUS/Modbus address for PZD10 Write (PPO Write).
Values 0 to 2 disable the PZD10 Write.
Default: 0
Min: 0
Max: FFFF
–
F7-70
(78AH)
PZD1 Read
Sets MEMOBUS/Modbus address for PZD1 Read (PPO Read).
Values 0 enable the PZD1 Read as ZSW.
Default: 0
Min: 0
Max: FFFF
–
F7-71
(78BH)
PZD2 Read
Sets MEMOBUS/Modbus address for PZD2 Read (PPO Read).
Values 0 enable the PZD2 Read as HIW.
Default: 0
Min: 0
Max: FFFF
–
F7-72
(78CH)
PZD3 Read
Sets MEMOBUS/Modbus address for PZD3 Read (PPO Read).
V
alues 0 disable the PZD3 Read.
Default: 0
Min: 0
Max: FFFF
–
No.(Addr.) Name Description Setting Page
