B.4 Control Mode Dependent Parameter Default Values
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 521
E3-01 (Motor 2 Control Mode) Dependent Parameters
Table B.4 E3-01 (Motor 2 Control Mode) Dependent Parameters and Default Values
o1-03 Digital Operator Display Selection 0 to 3 – 0 1 1
o1-04 V/f Pattern Display Unit 0 to 1 – – 1 1
<6> Default setting is determined by parameter o2-04, Drive Model Selection.
<14> Default setting value is dependent on the motor code set to parameter E5-01.
<18> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<41> This default value is a calculated as a percentage of the maximum output frequency.
<55> In AOLV/PM and CLV/PM control modes, the setting units and range are expressed as a percent (0.0 to 100.0%) instead of in Hz.
<56> In AOLV/PM and CLV/PM control modes, the setting units and range are expressed as a percent (0.0 to 40.0%) instead of in Hz.
<57> In AOLV/PM and CLV/PM control modes, the setting units and range are expressed as a percent (-100.0 to 100.0%) instead of in Hz.
No.
<9> Default setting is determined by the drive model (o2-04) and duty selection (C6-01).
<18> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
Name Setting Range Resolution
Control Modes (E3-01)
V/f (0) V/f w/PG (1) OLV (2) CLV (3)
C3-21 Motor 2 Slip Compensation Gain 0.0 to 2.5 0.1 0.0 – 1.0 1.0
C3-22 Motor 2 Slip Compensation Primary Delay Time 0 to 10000 1 ms 2000 – 200 –
C5-21 Motor 2 ASR Proportional Gain 1 0.00 to 300.00 0.01 – 0.20 – 20.00
C5-22 Motor 2 ASR Integral Time 1 0.000 to 10.000 0.001 s – 0.200 – 0.500
C5-23 Motor 2 ASR Proportional Gain 2 0.00 to 300.00 0.01 – 0.02 – 20.00
C5-24 Motor 2 ASR Integral Time 2 0.000 to 10.000 0.001 s – 0.050 – 0.500
C5-26 Motor 2 Carrier Frequency Selection 1 to F – 7 <9> 7 <9> 7 <9> 7 <9>
E3-04 Motor 2 Maximum Output Frequency 40.0 to 400.0 0.1 Hz 60.0 60.0 60.0 60.0
E3-05 Motor 2 Maximum Output Voltage <18> 0.0 to 255.0 0.1 V 200.0 200.0 200.0 200.0
E3-06 Motor 2 Base Frequency 0.0 to 400.0 0.1 Hz 60.0 60.0 60.0 60.0
E3-07 Motor 2 Mid Output Frequency 0.0 to 400.0 0.1 Hz 3.0 3.0 3.0 0.0
E3-08 Motor 2 Mid Output Frequency Voltage <18> 0.0 to 255.0 0.1 V 15.0 15.0 11.0 0.0
E3-09 Motor 2 Minimum Output Frequency 0.0 to 400.0 0.1 Hz 1.5 1.5 0.5 0.0
E3-10 Motor 2 Minimum Output Voltage <18> 0.0 to 255.0 0.1 V 9.0 9.0 2.0 0.0
E3-04 to
E3-10
The default setting of these parameters depends on the control mode but also on the drive capacity They are equivalent to the motor 1 settings. Refer to V/f Pattern Default
Values on page 522.
No. Name Setting Range Resolution
Control Modes (A1-02)
OLV/PM (5) AOLV/PM (6) CLV/PM (7)
