5.7 H: Terminal Functions
YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual 235
5.7 H: Terminal Functions
H parameters are used to assign functions to the external terminals.
H1: Multi-Function Digital Inputs
H1-01 to H1-08: Functions for Terminals S1 to S8
These parameters assign functions to the multi-function digital inputs. The various functions and their settings are listed
below in Table 5.35.
Table 5.35 Multi-Function Digital Input Terminal Settings
No.
<1> Number appearing in parenthesis is the default value after performing a 3-Wire initialization (A1-03 = 3330).
Parameter Name
Setting
Range
Default
H1-01 Multi-Function Digital Input Terminal S1 Function Selection 1 to 9F 40 (F) <1>: Forward Run Command (2-wire sequence)
H1-02 Multi-Function Digital Input Terminal S2 Function Selection 1 to 9F 41 (F) <1>: Reverse Run Command (2-wire sequence)
H1-03 Multi-Function Digital Input Terminal S3 Function Selection 0 to 9F 24: External Fault (N.O., always detected, coast to stop)
H1-04 Multi-Function Digital Input Terminal S4 Function Selection 0 to 9F 14: Fault Reset
H1-05 Multi-Function Digital Input Terminal S5 Function Selection 0 to 9F 3 (0) <1>: Multi-Step Speed Reference 1
H1-06 Multi-Function Digital Input Terminal S6 Function Selection 0 to 9F 4 (3) <1>: Multi-Step Speed Reference 2
H1-07 Multi-Function Digital Input Terminal S7 Function Selection 0 to 9F 6 (4) <1>: Jog Reference Selection
H1-08 Multi-Function Digital Input Terminal S8 Function Selection 0 to 9F 8: External Baseblock Command
Setting Function Page Setting Function Page
0 3-wire sequence 236 34 PID soft starter cancel 242
1 Local/remote selection 236 35 PID input level selection 242
2 External reference 1/2 selection 237 40 Forward run command (2-wire sequence)
242
3 Multi-Step Speed Reference 1
237
41 Reverse run command (2-wire sequence)
4 Multi-Step Speed Reference 2 42 Run command (2-wire sequence 2)
242
5 Multi-Step Speed Reference 3 43 FWD/REV command (2-wire sequence 2)
6 Jog reference selection 237 44 Offset frequency 1
242
7 Accel/decel time selection 1 237 45 Offset frequency 2
8 Baseblock command (N.O.)
237
46 Offset frequency 3
9 Baseblock Command (N.C.) 47 Node setup 242
A Accel/decel ramp hold 237 60 DC Injection Braking command 243
B Drive overheat alarm (OH2) 238 61 External Speed Search command 1 243
C Analog terminal input selection 238 62 External Speed Search command 2 243
D PG encoder disable 238 63 Field Weakening 243
E ASR integral reset 238 65 KEB Ride-Thru 1 (N.C.)
243
F Through mode 238 66 KEB Ride-Thru 1 (N.O.)
10 Up command
238
67 Communications test mode 243
11 Down command 68 High Slip Braking 243
12 Forward jog
239
6A Drive enabled 243
13 Reverse jog 71 Speed/Torque Control switch 244
14 Fault reset 239 72 Zero Servo 244
15 Fast Stop (N.O.) 239 75 Up 2 command
244
16 Motor 2 selection 240 76 Down 2 command
17 Fast Stop (N.C.) 239 77 ASR gain switch 244
18 Timer function input 240 78 External torque reference polarity inversion 244
19 PID disable 240 7A KEB Ride-Thru 2 (N.C.)
245
1A Accel/decel time selection 2 241 7B KEB Ride-Thru 2 (N.O.)
1B Program lockout 241 7C Short Circuit Braking (N.O.)
245
1E Reference sample hold 241 7D Short Circuit Braking (N.C.)
20 to 2F External fault 241 7E Forward/reverse detection 245
30 PID integral reset 242 7F Bi-directional PID output enable 245
31 PID integral hold 242 90 to 97 DriveWorksEZ Digital input 1 to 8 245
32 Multi-step speed reference 4 242 9F DriveWorksEZ disabled 245
