B.2 Parameter Groups
452 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
Parameter Differences for models CIMR-A4A0930 and 4A1200
Parameter Group Name Difference
A1 Initialization Parameters The setting range of A1-00 is 0 to 7. Refer to A1: Initialization Parameters on page 453.
b1 Operation Mode Selection b1-21 is not available in models CIMR-A4A0930 and 4A1200.
b2 DC Injection Braking and Short Circuit Braking b2-02, b2-03, and b2-04 are not available for OLV/PM in models CIMR-A4A0930 and 4A1200.
b3 Speed Search
• b3-04 is available in V/f and OLV. Refer to b3: Speed Search on page 456 for details.
• b3-07, b3-12, and b3-26 are available in models CIMR-A4A0930 and 4A1200.
• b3-29 and b3-33 are not available in models CIMR-A4A0930 and 4A1200.
b4 Timer Function b4-03 to b4-08 are not available in models CIMR-A4A0930 and 4A1200.
b5 PID Control The setting range of b5-01 is 0 to 4.
b8 Energy Saving b8-27 is not available in models CIMR-A4A0930 and 4A1200.
C3 Slip Compensation
• C3-05 is available in OLV, CLV, AOLV/PM, or CLV/PM (A1-02 = 2, 3, 6, 7). Refer to C3: Slip
Compensation on page 462 for details.
• C3-16 to C3-18 are available in models CIMR-A4A0930 and 4A1200.
C5 Automatic Speed Regulator (ASR) C5-39 is not available in models CIMR-A4A0930 and 4A1200.
C6 Carrier Frequency
• The setting range of C6-02 is 1, 2, or F.
• The setting range of C6-03 and C6-04 is 1.0 to 5.0 Hz. Refer to C6: Carrier Frequency on page 465 for
details.
• C6-09 is not available in models CIMR-A4A0930 and 4A1200.
E2 Motor 1 Parameters
For E2-05, the setting unit is m and the setting range is 0.000 m to 65.000 m. Refer to E2: Motor 1
Parameters on page 470 for details.
E4 Motor 2 Parameters
For E4-05, the setting unit is m and the setting range is 0.000 m to 65.000 m. Refer to E4: Motor 2
Parameters on page 472 for details.
E5 PM Motor Settings
E5-25 is available in OLV/PM, AOLV/PM, or CLV/PM (A1-02 = 5, 6, 7). Refer to E5: PM Motor
Settings on page 473.
F1 PG Speed Control Card (PG-B3/PG-X3/PG-RT3/PG-F3) F1-50 to F1-53 are not available in models CIMR-A4A0930 and 4A1200.
H2 Multi-Function Digital Outputs
• H2-07 to H2-10 are not available in models CIMR-A4A0930 and 4A1200.
•H2- cannot be set to D, 4E, 4F, 62, or 63.
H3 Multi-Function Analog Inputs H3- = 17 is available in models CIMR-A4A0930 and 4A1200.
H5 MEMOBUS/Modbus Serial Communication H5-18 are not available in models CIMR-A4A0930 and 4A1200.
L1 Motor Protection
• L1-08 and L1-09 are not available in models CIMR-A4A0930 and 4A1200.
• L1-15 to L1-20 are available in models CIMR-A4A0930 and 4A1200.
L3 Stall Prevention
• L3-04 cannot be set to 3.
• L3-34 and L3-35 are not available in models CIMR-A4A0930 and 4A1200.
L8 Drive Protection
• L8-01 and L8-55 are not available.
• The setting range of L8-29 is 0 or 1.
• L8-78 is available.
L9 Drive Protection 2 L9-03 is not available in models CIMR-A4A0930 and 4A1200.
n8 PM Motor Control Tuning
• n8-03, n8-04, n8-11 to n8-21, n8-36 to n8-39, and n8-72 are not available in models CIMR-A4A0930
and 4A1200.
• n8-02 is not available in CLV/PM control mode in models CIMR-A4A0930 and 4A1200.
T1 Induction Motor Auto-Tuning The setting range of T1-01 is 0 to 4, 8, or 9.
T2 PM Motor Auto-Tuning The setting range of T2-01 is 0 to 11.
U1 Operation Status Monitors
• The setting units of U1-03 is 1 A. Refer to U1: Operation Status Monitors on page 510 for details.
• U1-29 is available in models CIMR-A4A0930 and 4A1200.
U2 Fault Trace
• The setting units of U2-05 is 1 A. Refer to U2: Fault Trace on page 512 for details.
• U2-27 and U2-28 are available in models CIMR-A4A0930 and 4A1200.
U4 Maintenance Monitors
• The setting units of U4-13 is 1 A. Refer to U4: Maintenance Monitors on page 514 for details.
• U4-32, U4-37, U4-38, and U4-39 are available in models CIMR-A4A0930 and 4A1200.
